Item # 10055BR, 11 Gauge Wall Thickness and 7 Gauge Base Thickness Bump Release Self-Dumping Hopper

Item # 10055BR, 11 Gauge Wall Thickness and 7 Gauge Base Thickness Bump Release Self-Dumping Hopper

Engineered for safety and economy. Bump Release Hoppers are innovative and automatically dump on contact with the roll-off container. Hoppers are perfectly balanced to roll forward when loaded, dump completely and automatically return to upright, locked position ready for reloading. Continuous welding helps to prevent dripping of wet materials (leak-proof hoppers are available upon request). Formed smooth edge around top and pouring lip for safety and strength. Extended sides prevent side-wise scattering of material.

Specification
Brands Wright
Volume Capacity 1.0 yd³
Overall Width 39.75"
Overall Height 39.75"
Overall Length 67.5"
Fork Opening 3" BY 28.5"
Pouring Lip 3"
Container Length 63.5"
Dump Clearance Height 60.75"
Dump Clearance Bottom 7"
Dump Clearance Length 78.75"
Front Clearance 9.5"
Base Width 36.5"
Base Length 58"
Dump Angle 31°
Center of Gravity 25.5"
Approximate Weight 496 lb
Wall Thickness 11 Gauge
Base Thickness 7 Gauge
Features Bumper Release Self-Dumping Stackable
