Item # 2555LP, Low Profile Dumping Hoppers
Series “55” 1/8″ Steel (12 Gauge) Hopper with 3/16″ (7 Gauge) Steel Base
Note: All dimensions are approximate some dimensions may vary slightly per hopper.
- Specification
- Packaging
- Additional Information
- Downloads
-
Notice: Undefined index: title in /home/mcculloughind/public_html/wp-content/plugins/woocommerce/templates/single-product/tabs/tabs.php on line 38
Specification
| Volume Capacity | 1/4 yd³ |
| Overall Width A | 31 in |
| Overall Height B | 17 in |
| Overall Length C | 43 in |
| Fork Opening D | Fork Opening D |
| Container Length F | 33 5/8 in |
| Dump Clearance Height G | 38 1/2 in |
| Dump Clearance Bottom H | 18 1/2 in |
| Dump Clearance Length I | 37 3/4 in |
| Front Clearance J | 20 3/4 in |
| Base Width K | 22 3/8 in |
| Base Length L | 22 1/4 in |
| Dump Angle M | 90 º |
| Center Of Gravity N | 23 in |
| Weight Capacity | 4000 lb |
| Approximate Weight | 245 lb |
| Pouring Lip E | 0 in |
Packaging
| Packaging | N/A |
Additional Information
| Additional Information | N/A |
Downloads
| Safe Operations Video | Click Here |
| PDF File | N/A |
